4.9.2. Auto-lubrication device (optional)
It is possible to get a rack auto-lubrication device. The system and its tank are installed behind
the centrifugal brake (safety device) pannel.
To learn more about tank refill and rack lubricating periods, please refer to the periodic
maintenance section of the present manual.
Pass the device wiring through the frame and connect to the panel (CC1) as indicated in the
eletrical diagram.
Note : if the machine is not equipped with an auto-lubrication device, please refer to the manual
lubrication procedure.∞ REFER TO SECTION 9.8 RACK MANUAL LUBRICATION , ON PAGE 73.
Install the lubrication device with the suplied set of bolts.
