11 CHARTS
PROJECT MENU
Menu voice
Selectable options
Function
New…
—
Creates a new le.
Load…
—
Loads any existent le.
Save
—
Saves the changes made to the current project.
Save As…
—
Saves the current project as a new le.
Delete…
—
Deletes any existent le.
Rename…
—
Renames any existent le.
Aux Target
Reset / Run 1 / Run 2 / Run 3 /
Run 4
Selects the behavior of the external gate signal.
Master Track
1 / 2 / 3 / 4
Selects the Master Track.
ShowInPlay
No / Yes
Enable to display in real time the playing stage in PerformanceMode in the dash-
board.
0V is
C / A
Selects the Reference Note.
All Edits
From / All
Selects the behavior of the Set All and Shift All buttons.
Temperament
Absolute / Relative
Selects if the User Temperaments are applied to the Reference Note only, or to the
root note selected in each track (which may change).
Replace FW
—
Updates the current rmware (when a new rmware le is loaded into the SD
card).
TRACK MENU
Menu voice
Selectable options
Function
Int BPM
from 30 to 300
Select the internal clock speed expressed in BPM, the clock source, and the clock-
to-unit ratio, as expressed in the chapters about Tempo Management and Editing
Tracks.
ClockSource
Built-In / External
Ratio
…
Swing
0 − 50
Sets the Swing ratio.
Track Mode
Pattern / Song
Selects the track mode.
CV A Mode
Pitch / Raw
Sets the CV mode for channel A and B to raw voltages or quantized notes.
CV B Mode
Pitch / Raw
CV A Range
0/+10V / −/+5V
Denes if the CV range for channel A and B is unipolar or bipolar.
CV B Range
0/+10V / −/+5V
Root
C − B
Denes the root note and the scale in the default 12EDO system. See also the 12-
EDO scales section.
Scale
…
Quantize
Near Up / Near Down / Up /
Down
Selects the dynamic quantization direction.
Gate A % Width
10 − 90
Sets the time a gate stays high when in ratcheting mode (green color), expressed
in the % of the time between two consecutive rising edges.
Gate B % Width
10 − 90
Reset What
Nothing / Stage / Stage&Pa
Select the reset options.
Reset On
Instant / Local / Master
PitchShiftA
None / CV A / CV B
Sets the Pitch Shift source for CV A and B.
PitchShiftB
None / CV A / CV B
Root Shift
None / CV A / CV B
Sets the Root Shift source.
StageShift
None / CV A / CV B
Sets the Stage Shift source.
Ptrn Shift
None / CV A / CV B
Sets the Pattern Shift source.
PhaseShift
None / CV A / CV B
Sets the Phase Shift source.
Gate ShiftA
None / CV A / CV B
Sets the Gate Shift source for GATE A and B.
Gate ShiftB
None / CV A / CV B
Vari Shift
None / CV A / CV B
Sets the Variation Shift source.
TonesPerOct
…
Sets the octave division unit or the custom temperament.
Root 15
…
Select the reset options. Denes the root and scale for each of the other four oc-
tave divisions available. See also the following sections about. 15, 19, 22 and 24-
EDO scales.
Scale 15
…
Root 19
…
Scale 19
…
Root 22
…
Scale 22
…
Root 24
…
Scale 24
…
