Frap Tools CGM - Brenso

Rev. 5 – Jun 2020 Page 89 of 91
6 BRENSO
Parameter
Details
Min
Typ
Max
Unit
Current Draw
+12V
325
mA
-12V
235
Size
30
HP
Input details (1)
V/oct
Impedance
>90
KΩ
FM source
>30
Deviation CV
>90
Integrator CV
>40
Sync
>60
Minimum amplitude
2
Vpp
Suggested amplitude
±5
AM CV
Impedance
>40
KΩ
AM source
>90
Suggested amplitude
±5
Timbre Modulation source
Impedance
>40
KΩ
Timbre modulation CV
>90
Triangle Waveshape CV
>60
Pulse Waveshaper CV
>60
PWM CV
>90
Sources CV
>25
Wavefolder CV
>60
Wavefolder Symmetry CV
>50
Ping CV
>90
Output Details
Audio outputs
Impedance
>100
Ω
Amplitude (2)
±5
Vpp
Oscillators
Knob range
Audio rate
27.5
7040
Hz
LFO mode
0.15
10
V
~6.6
25
ms
Ratio (3)
176:1
Tracking (4)
±5
ȼ
Fine tuning
>1
st
(1) All buffered.
(2) Unloaded.
(3) Subject to ±3% tolerance.
(4) Measured at 440Hz over ±3 octaves.
7 333
Parameter
Details
Min
Typ
Max
Unit
Current Draw
+12V
48
mA
-12V
48
Size
6
HP
Input impedance
>90
KΩ
Output impedance
<50
Ω
CV Tolerance
<0.5
%
global offset per section
-20
20
mV
Frequency response (1)
DC
30
KHz
Harmonic Distortion (THD+N) (2)
<0.01
%
(1) Within 1dB, measured at +10dBu onto a 1KΩ load.
(2) Measured at 1KHz with output signal of +10dBu onto 1KΩ load with a 10Hz to 80KHz bandwidth measurement system.
8 321
Parameter
Details
Min
Typ
Max
Unit
Current Draw
+12V
48
mA
-12V
48
Size
6
HP
Input impedance
>90
KΩ
Output impedance
<50
Ω
Frequency response (1)
DC
19
KHz
(1) Within 1dB, measured at +10dBu onto a 1KΩ load.
