Fronius CU 1800 - Technical Description; Scope of Delivery; Water Hoses; Bypass Hose

86
Technical description
Scope of delivery
Water hoses
Connection cable
to interface box
Cooling liquid
44,0001,3398 Water hose Chiller l=5m (2 pc. /l=196,85inch)
42,0350,0006 Water hose Chiller l=12m (2 pc. /l=472,440inch)
44,0001,3399 Water hose Chiller - power source l=1,2m (2 pc.) (47,244inch)
38,0003,0205 Connection cable M12x1 4pin straight 5m
38,0003,0204 Connection cable M12x1 4pin straight 10m
40,0009,0180 Cooling liquid FLC10 5l
40,0009,0181 Cooling liquid FLC10 30l
Bypass hose
48,0001,0088 Length: 700 mm, Ø outside: 6 mm, Ø inside: 4 mm
(1)
(6)
(7)
(2)
(3)
(4)
(5)
(1) CU 1800 water chiller
(2) Bypass hose
(3) Cooling water connection: Inlet ow
(4) Cooling water connection: Outlet ow
(5) Filter
(6) Mounting bracket for water outlet ow (incl. mounting screws)
(7) Tool for lter change
(8) Mains cable (without picture)
