Fronius CU 1800 - Dimensions and Weight; Free Space for Air Circulation

90
Dimensions and
weight
Dimensions l/w/h without carriage 377 x 735 x 615 mm (14.8 x 28.9 x 24.2 in)
Dimensions l/w/h with carriage 653 x 800 x 857 mm (25.7 x 31.5 x 33.7 in)
Net weight (without circulating uids) 44,5 kg (98.10 lb)
Free space for air
circulation
A
B B
D
C
A min. 100 mm (3.94 in)
B min. 100 mm (3.94 in)
C min. 500 mm (19.70 in)
D min. 300 mm (11.80 in)
857 mm
800 mm
735 mm
500 mm
615 mm
653 mm
377 mm
