Fronius Symo Advanced 10.0-3-M User Manual

Fronius Symo Advanced 10.0-3-M
Nominal frequency
50 / 60 Hz
1)
Initial short circuit alternating current / phase I
K
20 A
Total harmonic distortion < 1.75%
Current (inrush)
5)
27.2 A peak /
5.18 A rms over 5.4 ms
4)
Power factor (cos phi)
0–1 ind./cap.
2)
Maximum output fault current / duration 64 A / 2.34 ms
General data
Maximum efficiency 97.8%
European efficiency U
DCmin
/ U
DCnom
/ U
DCmax
95.4 / 97.3 / 96.6%
Self-consumption at night 0.7 W & 117 VA
Cooling
Controlled forced-air
ventilation
Protection class IP 66
Dimensions h x w x d 725 x 510 x 225 mm
Weight 34.8 kg
Permitted ambient temperature -25 °C - +60 °C
Permissible humidity 0-100%
EMC emission class B
DC / AC overvoltage category 2 / 3
Pollution degree 2
Noise emission 65 dB(A) (ref. 1pW)
Inverter topology Non-insulated trans-
formerless
Protection devices
DC isolation measurement Integrated
DC overload performance
Operating point shift,
power limiter
DC disconnector Integrated
RCMU Integrated
Active anti-islanding method Frequency conversion
method
AFCI - Arc Fault Circuit Interrupter (Arc Guard) Integrated
AFPE (AFCI) classification (according to
IEC63027)
F-I-AFPE-1-6-1
Full coverage
Integrated
AFPE
1 monitored string per in-
put port
6 input ports per channel
(AFPE for MPP1 & MPP2:
6)
1 monitored channel
113
EN

Fronius Symo Advanced 10.0-3-M Specifications

General

AC nominal output	10.0 kW
Max. efficiency	98.1%
MPPT voltage range	200 - 800 V
Number of MPPT	2
Protection class	IP66
Max. output current	14.5 A
THD	< 3%
Max. input voltage	1000 V
Operating temperature range	-25°C - +60°C
Max. apparent AC power	10 kVA
AC nominal voltage	400 V
Power factor (cos φac,r)	1
DC max. power	15, 000 W
Warranty	5 years
Cooling	Fan
