SETUP menu item
Initial setting The inverter is pre-configured after commissioning has been completely carried
out (e.g. using the Installation Wizard) according to the country setup.
The SETUP menu item allows the initial settings of the inverter to be changed
easily to bring it in line, as closely as possible, with the preferences and require-
ments of the user.
Software up-
dates
IMPORTANT! As a result of software updates, you may find that your device has
certain functions that are not described in these Operating Instructions, or vice
versa. Certain illustrations may also differ slightly from the actual controls on
your device, but these controls function in exactly the same way.
Navigating the
SETUP menu
item
Entering the SETUP menu item
GRAPH
1
At the menu level, use the "Left" or
"Right" keys to select the "SETUP"
menu item
2
Press the "Enter" key
Relay
The first entry under the SETUP menu item
is displayed:
"Standby"
Scrolling between the entries
Relay
3
Use the "Up" and "Down" keys to
scroll between the available entries
Exiting an entry
GRAPH
4
To exit a menu entry, press the "Back"
key
The menu level appears
If no key is pressed for 2 minutes:
76

Fronius Symo Advanced 10.0-3-M Specifications

General

AC nominal output	10.0 kW
Max. efficiency	98.1%
MPPT voltage range	200 - 800 V
Number of MPPT	2
Protection class	IP66
Max. output current	14.5 A
THD	< 3%
Max. input voltage	1000 V
Operating temperature range	-25°C - +60°C
Max. apparent AC power	10 kVA
AC nominal voltage	400 V
Power factor (cos φac,r)	1
DC max. power	15, 000 W
Warranty	5 years
Cooling	Fan
