Fronius Symo
Advanced
17.5-3-M
Fronius Symo Advanced 17.5-3-M
Input data
MPP voltage range 370–800 V DC
Max. input voltage
(at 1000 W/m²/ -10 °C in an open circuit)
1000 V DC
Min. input voltage 200 V DC
Max. input current (MPP1 / MPP2)
(MPP1 + MPP2)
33.0 / 27.0 A
51.0 A
Max. input current per string with activated AFCI
(AFPE)
12 A
Max. short circuit current of the solar modules
(I
SC PV
) (MPP1 / MPP2)
68 / 55.7 A
Max. inverter backfeed current to the array
3)
49.5 / 40.5 A
Insulation resistance test limit value between
module array and earth (on delivery)
7)
100 kΩ
Adjustable range of insulation resistance test
between module array and earth
6)
100–10,000 kΩ
Limit value and tripping time of the sudden resid-
ual current monitoring (on delivery)
30 / 300 mA / ms
60 / 150 mA / ms
90 / 40 mA / ms
Limit value and tripping time of the continuous re-
sidual current monitoring (on delivery)
300 / 300 mA / ms
Adjustable range of continuous residual current
monitoring
6)
- mA
Cyclic repetition of the insulation resistance test
(on delivery)
24 h
Adjustable range for the cyclic repetition of the
insulation resistance test
-
Output data
Nominal output power (P
nom
) 17,500 W
Max. output power 17,500 W
Rated apparent power / S
RATED
17,500 VA
Nominal mains voltage 3~ NPE 400 / 230 V or 3~
NPE 380 / 220
Min. grid voltage 150 V / 260 V
Max. grid voltage 280 V / 485 V
Nominal output current at 220 / 230 V 26.5 / 25.4 A
Max. output current 32 A
Nominal frequency
50 / 60 Hz
1)
Initial short circuit alternating current / phase I
K
32 A
Total harmonic distortion < 1.5%
118
