Fronius Symo Advanced 10.0-3-M User Manual

Settings
Rated breaking capa-
city
Rated
operating
voltage
(Ue)
[V d.c.]
Rated
operating
current
(Ie)
[A]
2P
I(make) /
I(break)
[A]
2P
Rated
operating
current
(Ie)
[A]
2 + 2P
I(make) /
I(break)
[A]
2 + 2P
≤ 500 32 128 50 200
600 27 108 35 140
700 22 88 22 88
800 17 68 17 68
900 12 48 12 48
1000 6 24 6 24
Integrated DC
disconnector
Fronius Symo
Advanced 15.0 -
20.0
Settings
Product name Benedict LS32 E 7858
Rated insulation
voltage
1000 V
DC
Rated impulse with-
stand voltage
8 kV
Suitability for insula-
tion
Yes, DC only
Utilisation category
and / or PV utilisa-
tion category
As per IEC/EN 60947-3 utilisation category DC-PV2
Rated short-time
withstand current
(Icw)
Rated short-time withstand current (Icw): 1400 A for 2
poles; 2400 A for 2+2 poles
Rated short-circuit
making capacity
(Icm)
Rated short-time withstand current (Icm): 1400 A for 2
poles; 2400 A for 2+2 poles
Rated breaking capa-
city
Rated
operating
voltage
(Ue)
[V d.c.]
Rated
operating
current
(Ie)
[A]
2P
I(make) /
I(break)
[A]
2P
Rated
operating
current
(Ie)
[A]
2 + 2P
I(make) /
I(break)
[A]
2 + 2P
≤ 500 55 220 85 340
600 55 220 75 300
700 55 220 60 240
800 49 196 49 196
900 35 140 35 140
1000 20 80 25 100
123
EN

Fronius Symo Advanced 10.0-3-M Specifications

General

AC nominal output	10.0 kW
Max. efficiency	98.1%
MPPT voltage range	200 - 800 V
Number of MPPT	2
Protection class	IP66
Max. output current	14.5 A
THD	< 3%
Max. input voltage	1000 V
Operating temperature range	-25°C - +60°C
Max. apparent AC power	10 kVA
AC nominal voltage	400 V
Power factor (cos φac,r)	1
DC max. power	15, 000 W
Warranty	5 years
Cooling	Fan
