Explanation of
footnotes
1) The values stated are defaults; the inverter is configured specifically to
suit the requirements of the relevant country.
2) Depending on the country setup or device-specific settings
(ind. = inductive; cap. = capacitive).
3) Maximum current from a defective PV module to all other PV modules.
From the inverter itself to the PV side of the inverter, it is 0 A.
4) Guaranteed by the electrical configuration of the inverter
5) Current peak when switching on the inverter
6) Specified values are standard values; depending on the requirement and
PV power, these values must be adjusted accordingly.
7) Specified value is a max. value; exceeding the max. value may negatively
affect the function.
8)
I
SC PV
= I
SC max
≥ I
SC
(STC) x 1.25 according to e.g.: IEC 60364-7-712,
NEC 2020, AS/NZS 5033:2021
WLAN
WLAN
Frequency range 2412–2462 MHz
Channels / power used Channel: 1–11 b,g,n HT20
Channel: 3–9 HT40
<18 dBm
Modulation 802.11b: DSSS (1 Mbps DBPSK,
2 Mbps DQPSK, 5.5/11 Mbps CCK)
802.11g: OFDM (6/9 Mbps BPSK,
12/18 Mbps QPSK, 24/36 Mbps 16-
QAM, 48/54 Mbps 64-QAM)
802.11n: OFDM (6.5 BPSK, QPSK,
16-QAM, 64-QAM)
Integrated DC
disconnector
Fronius Symo
Advanced
10.0-12.5
Settings
Product name Benedict LS32 E 7857
Rated insulation
voltage
1000 V
DC
Rated impulse with-
stand voltage
8 kV
Suitability for insula-
tion
Yes, DC only
Utilisation category
and / or PV utilisa-
tion category
As per IEC/EN 60947-3 utilisation category DC-PV2
Rated short-time
withstand current
(Icw)
Rated short-time withstand current (Icw): 1000 A for 2
poles; 1700 A for 2+2 poles
Rated short-circuit
making capacity
(Icm)
Rated short-time withstand current (Icm): 1000 A for 2
poles; 1700 A for 2+2 poles
122
