The airflow within the inverter is from the right to the top (cold air taken in
from the right, hot air dissipated out of the top).
The exhaust air can reach a temperature of 70 °C.
When installing the inverter in a switch cabinet or similar closed environment,
it is necessary to make sure that the hot air that develops will be dissipated by
forced-air ventilation.
If the inverter is to be installed on the outer wall of a cattle shed, maintain a
minimum all-round clearance of 2 m between the inverter and all ventilation
and other openings in the building.
The installation location must not be exposed to ammonia, corrosive vapours,
salts or acids.
