Fronius Symo Advanced 10.0-3-M User Manual

An overview of the values that can be
changed is displayed.
3
Use the "Up" and "Down" keys Select
"Set time"
4
Press the "Enter" key
The current time appears. (HH:MM:SS, 24-
hour clock), the "tens" digit for the hour will
flash.
5
Use the "Up" and "Down" keys to se-
lect a value for the first digit of the code
6
Press the "Enter" key
The "units" digit for the hour will flash.
7
Repeat steps 5 and 6 to set the "units"
digit for the hour, for the minutes and for
the seconds until...
the set time starts flashing.
8
Press the "Enter" key
The time is applied and the overview of val-
ues that can be changed is displayed.
4
Press the "Esc" key
The "Clock" item on the Setup menu ap-
pears.
78

Fronius Symo Advanced 10.0-3-M Specifications

General

AC nominal output	10.0 kW
Max. efficiency	98.1%
MPPT voltage range	200 - 800 V
Number of MPPT	2
Protection class	IP66
Max. output current	14.5 A
THD	< 3%
Max. input voltage	1000 V
Operating temperature range	-25°C - +60°C
Max. apparent AC power	10 kVA
AC nominal voltage	400 V
Power factor (cos φac,r)	1
DC max. power	15, 000 W
Warranty	5 years
Cooling	Fan
