Fronius Symo Advanced 10.0-3-M User Manual

Do not disconnect
USB-Stick
while LED is flashing!
X
IMPORTANT! To avoid any loss of
data, a USB flash drive may only be
removed if the following conditions
are met:
-
Only remove a USB flash drive
via the 'Safely remove USB /
HW' item on the SETUP menu
-
The 'Data transmission' LED has
stopped flashing or comes on
steady.
95
EN

Fronius Symo Advanced 10.0-3-M Specifications

General

AC nominal output	10.0 kW
Max. efficiency	98.1%
MPPT voltage range	200 - 800 V
Number of MPPT	2
Protection class	IP66
Max. output current	14.5 A
THD	< 3%
Max. input voltage	1000 V
Operating temperature range	-25°C - +60°C
Max. apparent AC power	10 kVA
AC nominal voltage	400 V
Power factor (cos φac,r)	1
DC max. power	15, 000 W
Warranty	5 years
Cooling	Fan
