AC output data PV Point
Nominal frequency
53 / 63 Hz
1)
Switchover time < 90 s
Power factor cos phi
2)
0 - 1
General data
Maximum efficiency 98.1%
European efficiency (U
mpp nom
) 96.7%
European efficiency (U
mpp max
) 96%
European efficiency (U
mpp min
) 95.1%
Self-consumption at night < 10 W
Cooling Controlled forced-air ventilation
Protection class IP 66
Dimensions H x W x D 530 x 474 x 165 mm
Weight 16.5 kg
Inverter topology Non-insulated transformerless
Permitted ambient temperature -25 °C – +60 °C
Permissible humidity 0–100% (incl. condensation)
EMC device class B
DC/AC overvoltage category
(in accordance with IEC 62109-1)
2/3
Pollution degree 2
Sound pressure 36 dB(A)
Safety class (according to IEC62103) 1
Protection devices
DC isolation measurement Warning / shutdown at R
ISO
<
100 kOHM
Overload performance Operating point shift, power limiter
DC disconnector Integrated
RCMU Integrated
RCMU classification The software class of the safety plat-
form(s) is specified as a class B con-
trol function (single channel with peri-
odic self-test) according to IEC60730
Annex H.
Active anti-islanding method Frequency conversion method
Power per digital output
(for external supply)
1 A at >12.5 V-24 V
(max. 3 A in total)
Datalogger/web server Integrated
146
