The following values can be selected for the rules of the time-dependent battery
control:
-
"Max charging power"
The battery is charged with the value set in the input field "Power" at most.
-
"Min charging power"
The battery is charged with the value set in the input field "Power" at minim-
um.
-
"Max discharge power"
The battery is discharged with the value set in the input field "Power" at
most.
-
"Min discharge power"
The battery is discharged with the value set in the input field "Power" at min-
imum.
The timing, when the rule applies, is set in the "Time" input fields and by select-
ing from the "Weekdays".
It is not possible to define a time window over midnight (00:00).
Example: 2 entries are needed to set a regulation from 22:00 to 06:00: "22:00 -
23:59" and "00:00 - 06:00".
Examples -
Time-dependent
battery control
The examples below serve to explain the energy flows. Efficiency levels are not
taken into account.
Example: Battery system
PV system available power 1000 W
Power into the battery 500 W
Power output (AC) of the inverter 500 W
Target value set at feed-in point 0 W
Infeed into the public grid 0 W
Consumption in home 500 W
TARGET: 0W
0 W
500 W
1000 W
500 W
Example: Battery system without photovoltaics, including second producer in
the house
Power into the battery 1500 W
Power consumption (AC) of the inverter 1500 W
90
