4) Guaranteed by the electrical configuration of the inverter
5) For backup power mode (PV Point) without battery, a minimum voltage of
150 V is required.
6) Current peak when switching on the inverter.
7) Specified values are standard values; depending on the requirement and
PV power, these values must be adjusted accordingly.
8) Specified value is a max. value; exceeding the max. value may negatively
affect the function.
9) The system solution with suitable disconnection device in the event of a
fault for the voltage range up to max. 700 V is currently not available.
Integrated DC
disconnector
General data
Product name Benedict LS32 E 7905
Rated insulation
voltage
1000 V
DC
Rated impulse with-
stand voltage
8 kV
Suitability for insu-
lation
Yes, DC only
Utilisation category
and / or PV utilisa-
tion category
In accordance with IEC/EN 60947-3 utilisation category
DC-PV2
Rated short-time
withstand current
(l
cw
)
Rated short-time withstand current (l
cw
): 1000 A
Rated short-circuit
making capacity
(l
cm
)
Rated short-circuit making capacity (l
cm
): 1000 A
Rated operating current and rated breaking capacity
Rated operating
voltage (U
e
)
Rated operating
current (l
e
)
I
(make)
/
I
(break)
Rated operating
current (l
e
)
I
(make)
/
I
(break)
≤ 500 V
DC
14 A 56 A 36 A 144 A
600 V
DC
8 A 32 A 30 A 120 A
700 V
DC
3 A 12 A 26 A 88 A
800 V
DC
3 A 12 A 17 A 68 A
900 V
DC
2 A 8 A 12 A 48 A
1000 V
DC
2 A 8 A 6 A 24 A
Number of pins 1 1 2 2
155
EN
