Copper: round, solid
-
Copper: round, fine-stranded
IMPORTANT!
Connect the individual conductors to an appropriate ferrule if several individual
conductors are connected to one input of the push-in terminals.
WSD connections with push-in terminal
Dis-
tance
max.
Strip-
ping
length
Solid
Fine-stran-
ded
Fine-stran-
ded with fer-
rules with
collar
Fine-stran-
ded with fer-
rules without
collar
Cable re-
commenda-
tion
100 m
109 yd
10 mm
0.39 inch
0.14 -
1.5 mm
2
AWG 26 - 16
0.14 -
1.5 mm
2
AWG 26 - 16
0.14 - 1 mm
2
AWG 26 - 18
0.14 -
1.5 mm
2
AWG 26 - 16
min. CAT 5
UTP (un-
shielded
twisted pair)
Modbus connections with push-in terminal
Dis-
tance
max.
Strip-
ping
length
Solid
Fine-stran-
ded
Fine-stran-
ded with fer-
rules with
collar
Fine-stran-
ded with fer-
rules without
collar
Cable re-
commenda-
tion
300 m
328 yd
10 mm
0.39 inch
0.14 -
1.5 mm
2
AWG 26 - 16
0.14 -
1.5 mm
2
AWG 26 - 16
0.14 - 1 mm
2
AWG 26 - 18
0.14 -
1.5 mm
2
AWG 26 - 16
min. CAT 5
STP (shiel-
ded twisted
pair)
IO connections with push-in terminal
Dis-
tance
max.
Strip-
ping
length
Solid
Fine-stran-
ded
Fine-stran-
ded with fer-
rules with
collar
Fine-stran-
ded with fer-
rules without
collar
Cable re-
commenda-
tion
30 m
32 yd
10 mm
0.39 inch
0.14 -
1.5 mm
2
AWG 26 - 16
0.14 -
1.5 mm
2
AWG 26 - 16
0.14 - 1 mm
2
AWG 26 - 18
0.14 -
1.5 mm
2
AWG 26 - 16
Single con-
ductor pos-
sible
LAN connections
Fronius recommends at least CAT 5 STP (Shielded Twisted Pair) cables and a maximum distance of
100 m (109 yd).
Cross section of
the AC cable
For a standard M32 metric screw joint with a reducer:
Cable diameter from 7 - 15 mm
When using an M32 metric screw joint (reducer removed):
cable diameter from 11-21 mm
(with a cable diameter of less than 11 mm, the strain-relief force is reduced from
100 N to a maximum of 80 N)
50
