Fronius Symo GEN24 3.0 User Manual

IMPORTANT! To ensure reliable operation with a BYD Battery-Box Premium, the
following switch-on sequence for the system must always be observed.
1
Switch on the battery.
2
Set the DC disconnector to the "On"
switch position. Switch on the auto-
matic circuit breaker.
LG RESU FLEX
LG RESU FLEX 8.6 12.9 17.2
Fronius Symo GEN24 3.0 - 10.0*
Fronius Symo GEN24 3.0 - 10.0 Plus
Number of battery modules 2 3 4
* Battery support optionally available.
24

Fronius Symo GEN24 3.0 Specifications

General

Category	Inverter
Output Power	3.0 kW
Protection Rating	IP66
Max. apparent AC power	3.0 kVA
THD	< 3 %
Number of MPP trackers	2
Max. DC power	4.5 kW
Model	Symo GEN24 3.0
Communication Interfaces	Ethernet, Wi-Fi
AC grid connection	Single-phase
Battery voltage range	40 V - 56 V
Max. charging / discharging power	3 kW
Operating Temperature Range	-25°C - +60°C
