IMPORTANT!
When configuring the backup power mode "PV Point", the notes in the chapter
Safety on page 66 must be observed.
Backup power nominal voltage
When backup power mode is activated, the nominal voltage of the public grid
must be selected.
State of charge warning limit
A warning is output when the residual capacity of the battery specified here is
reached in backup power mode.
Reserve capacity
The set value results in a residual capacity (depending on the capacity of the bat-
tery) that is reserved for backup power. The battery is not discharged below the
residual capacity in grid-connected operation.
Load management
Up to 4 pins can be selected for load management here. Additional load manage-
ment settings are available in the "Load management" menu item.
Default: Pin 1
Australia - Demand Response Mode (DRM)
The pins for control via DRM can be set here:
Mode Description Information DRM pin
I/O
pin
DRM0 Inverter disconnects
itself from the grid
DRM0 occurs if there is
an interruption or short
circuit on the REF GEN
or COM LOAD leads, or if
the combinations DRM1
- DRM8 are invalid.
The mains relays open.
REF GEN
COM
LOAD
IO4
IO5
DRM1 Import P
nom
≤ 0%
without disconnec-
tion from the grid
currently not supported DRM 1/5 IN6
DRM2 Import P
nom
≤ 50% currently not supported DRM 2/6 IN7
DRM3 Import P
nom
≤ 75%
&
+Q
rel
* ≥ 0%
currently not supported DRM 3/7 IN8
DRM4 Import P
nom
≤ 100% currently not supported DRM 4/8 IN9
DRM5 Export P
nom
≤ 0%
without disconnec-
tion from the grid
currently not supported DRM 1/5 IN6
DRM6 Export P
nom
≤ 50% currently not supported DRM 2/6 IN7
DRM7 Export P
nom
≤ 75% &
-Q
rel
* ≥ 0%
currently not supported DRM 3/7 IN8
DRM8 Export P
nom
≤ 100% currently not supported DRM 4/8 IN9
The percentages always refer to the nominal device output.
IMPORTANT!
If the Demand Response Mode (DRM) function is enabled and no DRM control is
connected, the inverter switches to Standby mode.
85
EN
