92
I-G
I (current)-Ground - Ground current
Unit % (of main current I
1
)
Setting range 0 - 100
Factory setting 50
tri
trigger - Mode selection
Unit -
Setting range 2t / 4t
2t = 2-step mode
4t = 4-step mode
SPt
Spot welding time
Unit s
Setting range OFF / 0.01 - 9.9
Factory setting OFF
For further information on the SPt parameter, see the TIG set-up menu.
t-S
time-Starting - Starting current duration
Unit s
Setting range OFF / 0.01 - 9.9
Factory setting OFF
For further information on the t-S parameter, see the TIG set-up menu.
t-E
time-End - Final current duration
Unit s
Setting range OFF / 0.01 - 9.9
Factory setting OFF
For further information on the t-E parameter, see the TIG set-up menu.
POL
Polarity - Polarity of the welding current
Unit -
Setting range AC / nEG / POS
AC = AC welding
nEG = DC- welding
POS = DC+ welding
ACF
AC frequency
Unit Hz
Setting range Syn / 40 - 250
Factory setting 60
For further information on the ACF parameter, see the
AC / polarity reversal set-up menu.
