Specifications
509
Appendix
15
Continuous Copy Speed [Monochrome] [Color]
A4 , B5 : 20 sheets/minute 20 sheets/minute
A4 : 16 sheets/minute 16 sheets/minute
B4 : 13 sheets/minute 13 sheets/minute
B5 : 11 sheets/minute 11 sheets/minute
A3 : 11 sheets/minute 11 sheets/minute
Important • When paper is fed from Tray 5 and the paper size is set to
[Auto Detect], the printing speed for the first page will be
slower.
• The speed may be reduced due to image quality
adjustment.
• The performance may be reduced depending on the paper
type or paper tray.
• When paper in width narrower than B5, such as postcards,
is output continuously, the temperature on the fuser unit
becomes high. As a result, the machine may suspend the
output, displaying a message "Please wait", and may
resume in 1 minute. Also, for paper A5 or smaller, even after
1 sheet of paper is output, the machine may suspend with a
"Please wait" message and may resume in 30 seconds.
Paper Tray Capacity Standard:
560 sheets × 4 trays + 50 sheets (bypass tray)
Maximum paper capacity:
2,290 sheets (standard)
Important • When using 80 gsm paper
Continuous Copy 999 images
Note • The machine may pause temporarily to perform image
stabilization.
Output Tray Capacity Exit 2 Tray: approximately 250 sheets (A4 )
Center tray: approximately 250 sheets (A4 )
approximately 200 sheets (A3)
Important • When using 80 gsm paper
Power Supply AC 220 - 240 V±10%/110 V±10%, 10/15A for both 50/60 Hz±3%
Power Consumption Maximum power consumption: 1.76 kW (AC 220 V±10%)
1.92 kW (AC 240 V±10%)
1.65 kW (AC110 V±10%)
Sleep mode: 3 W or less (AC 110 V)
3.5 W or less (AC 220 - 240 V)
Standby mode: 130 W or less
Dimensions Copier/printer model:
Width 607 × Depth 640 × Height 1,046 mm
Copier/printer/scanner model:
Width 607 × Depth 640 × Height 1,132mm
(with Duplex Automatic Document Feeder)
Machine Weight 109 kg
115 kg (with the Fax feature and Duplex Automatic Document
Feeder attached)
Important • The weight of paper and the toner cartridges is not included.
