3 Maintenance
72
Maintenance
3
5 Hold the fuser unit by the grips on both
sides, and remove the fuser unit from the
machine.
Important • The fuser unit weights approximately 2.5
kg. Be careful not to drop the unit.
6 Take out a new fuser unit from the box.
7 Hold the new fuser unit by the grips on both
sides, and then place the fuser unit onto the
machine.
Important • Hold the fuser unit with both hands so that
you do not drop it.
8 While holding the fuser unit with one hand,
tighten the screws on both sides with the
other hand.
9 Push the center of the top left cover and
close the cover gently, and then close Tray 5.
10 Switch on the main power, and then switch on the power.
For information on how to switch on the power and the main power, refer to "2 Product Overview" >
"Power Source" in the User Guide.
Replacing IBT Unit
When the IBT Unit is near or reaches the end of its life, the following messages are
displayed on the touch screen. Follow the messages.
Message Remaining Page Yield Solution
Consumables need to be
ordered.
Press Machine Status
button and select the
Supplies tab for details.
Approx. 1,500 pages Order the IBT Unit.
Consumables need to be
replaced.
Press Machine Status
button and select the
Supplies tab for details.
-
Replace the IBT Unit with a
new one.
To Next Page
