HP-GL2 Emulation
555
Appendix
15
Folding 168 Specify how to hold outputs.
[0] (Default) : Off
[1] : Z Fold Half Sheet
Emulation target
printer
169 Select the machine to emulate.
[0] (Default) : HP750
[1]1 : FX4036
Pen attributes 800-815 (Pen
width)
(No. 0-No.15)
Set the width (thickness of the line) of the 16 pens (No. 00 to 15). You can
set the width from 0.0 to 25.2 mm in 0.1 mm increments. No. 00 denotes
Item No. 800.
[0] - [255] (Default: 3) : 0 to 25.5 mm
Note • If the image is reduced by concern with the relationship between
[Document size] and [Paper size] settings, the pen width is reduced
accordingly to 0.1 mm at the smallest.
• The width of the line gets thick symmetrically with respect to the
center of the line.
• If the width is set to 0.0 mm, nothing is plotted.
850-865 (Line
end shape)
(No. 0-No.15)
Set the line end shape of the 16 pens (No. 00 to 15). No. 00 denotes Item
No. 850.
[0] (Default) : Cut
[1] : Round
[2] : Rectangular
[Cut]
: specified coordinate
[Round]
: specified coordinate
[Rectangular]
: specified coordinate
Parameter Item No. Value
