Basic Operation 45
DocuPrint CM215 b
1 Output Tray Extension 2 Center Output Tray
3 Operator Panel 4 Document Cover
5 Toner Access Cover 6 Document Glass
7 Print Head Cleaning Rod 8 Power Switch
9 Front Cover 10 Paper Width Guides
11 Slide Bar 12 Length Guide
13 Multipurpose Feeder (MPF)14USB Drive
15 Priority Sheet Inserter (PSI)
3
4
5
6
10
15
14
13 12 11
10 9
8
1
2
7
