82 Printer Connection and Software Installation
îš„ Assigning an IP Address Manually
NOTE:
• Assigning an IP address is considered as an advanced function and is normally done by a system
administrator.
• Depending on the address class, the range of the IP address assigned may be different. On Class A, for
example, an IP address in the range from 0.0.0.0 to 127.255.255.255 will be assigned. For assignment
of IP addresses, contact your system administrator.
You can assign the IP address by using the operator panel or using the Printer Setting Utility.
For Microsoft
®
Windows
®
, you can also assign the IP address to the printer using the installer on the
Software Pack CD-ROM.
Using the Operator Panel
1 On the operator panel, press the (System) button.
2 Select Admin Menu, and then press the button.
3 Select Network, and then press the button.
4 Select TCP/IP, and then press the button.
5 Select IPv4, and then press the button.
6 Select Get IP Address, and then press the button.
7 Select Panel, and then press the button.
8 Press the (Back) button,
Confirm that Get IP Address appears.
9 Select IP Address, and then press the button.
The cursor is located at the first digit of the IP address.
10 Enter the value of the IP address using the or button.
11 Press the button.
The next digit is selected.
12 Repeat steps 11 to 12 to enter all of the digits in the IP address, and then press the button.
13 Press the (Back) button.
Confirm that IP Address appears.
14 Select Subnet Mask, and then press the button.
The cursor is located at the first digit of the subnet mask.
15 Enter the value of the subnet mask using the or button.
To Next Page
