Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
Remove the PSU and install the dummy cover carefully.
Note for PSU1:
Remove the PSU1 carefully while lifting PSU1 and bringing PSU1 to
the right, in order to avoid interference.
▶
Mount the complete assembly (CMA stopper
, the crossbar and the CMA)
again into the rail.
Preliminary steps
▶
Only when replacing a PSU in a non-redundant configuration: "Shutting
down the server" on page
45
.
▶
Remove the power cord from the PSU, see "Disconnecting the power cord"
on page 46.
Removing a hot-plug PSU
Figure 36: Removing the PSU
▶
Push the handle of the PSU halfway upward in the direction of the arrow (1).
▶
Press in on the green locking latch (2).
Power supply unit (PSU)
RX1330 M4 Upgrade and Maintenance Manual 111

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
