Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

8.2 Basic information 177
8.3 Replacing fan modules 179
9 Expansion cards and backup units 183
9.1 Safety notes 183
9.2 Basic information 184
9.3 Handling slot brackets 185
9.3.1 Installing slot brackets 185
9.3.2 Removing slot brackets 187
9.4 Handling SFP+ transceiver modules 188
9.4.1 Installing SFP+ transceiver modules 188
9.4.2 Removing SFP+ transceiver modules 193
9.5 Expansion cards and riser cards 196
9.5.1 Installing an expansion card 196
9.5.2 Removing an expansion card 203
9.5.3 Replacing an expansion card 205
9.5.4 Replacing a riser card 207
9.5.5 Replacing a TFM 209
9.5.6 Upgrading to the full height riser module 214
9.6 Flash backup unit (FBU) 218
9.6.1 Basic information 218
9.6.2 Installing an FBU 219
9.6.3 Removing an FBU 227
9.6.4 Replacing an FBU 231
10 Main memory 233
10.1 Safety notes 233
10.2 Basic informations 234
10.3 Installing memory modules 235
Content
Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
