Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

7 Hard disk drive (HDD) / solid state drive (SSD) 133
7.1 Safety notes 133
7.2 Basic information 134
7.3 Handling HDDs or SSDs without installation frame 135
7.3.1 2.5-inch HDD/SSD and 2.5-inch installation frame 135
7.3.2 2.5-inch HDD/SSD and 3.5-inch installation frame 136
7.3.3 3.5-inch HDD and 3.5-inch installation frame 138
7.4 3.5-inch HDD configurations 140
7.4.1 Overview of configurations 140
7.4.1.1 Configuration with up to four HDD modules 140
7.4.2 Installing 3.5-inch HDD modules 141
7.4.3 Removing 3.5-inch HDD modules 143
7.4.4 Replacing a 3.5-inch HDD module 145
7.4.5 Replacing the 3.5-inch HDD backplane 147
7.5 2.5-inch HDD/SSD configurations 150
7.5.1 Overview of configurations 150
7.5.1.1 Configuration with up to four HDD/SSD modules 150
7.5.1.2 Configuration with up to eight HDD/SSD modules 151
7.5.1.3 Configuration with up to ten HDD/SSD modules 152
7.5.2 Installing 2.5-inch HDD/SSD modules 152
7.5.3 Removing 2.5-inch HDD/SSD modules 155
7.5.4 Replacing a 2.5-inch HDD/SSD module 157
7.5.5 Replacing the 4 x 2.5-inch HDD backplane (left side) 159
7.5.6 Replacing the 4 x 2.5-inch HDD backplane (right side) or PCIe
SSD backplane 163
7.5.7 Replacing the 10 x 2.5-inch HDD backplane 167
7.5.8 Replacing the SAS expander board 172
7.5.9 Upgrading configuration from up to four to up to eight 2.5-inch
HDDs/SSDs 173
8 Fans 177
8.1 Safety notes 177
Content
RX1330 M4 Upgrade and Maintenance Manual

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
