Figure 44: Connecting the front USB cable and the front panel cable
▶
If disconnected before: connect the front panel cable and the front USB
cable to the system board.
Ensure that the front panel cable is situated under the front USB
cable.
For the cable plans, see "Appendix B" on page 365
.
Power supply unit (PSU)
RX1330 M4 Upgrade and Maintenance Manual 121
