Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Depending on ATD support, there are different heat sinks available.
4x3,5"
4x / 8x 2,5"
Heatsink Fan Heatsink Fan Heatsink Fan
Xeon E-21xx (without Graphics)
Xeon E-2124 4C/4T 3.3GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2134 4C/8T 3.5GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2136 6C/12T 3.3GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-21xxG (with Graphics)
Xeon E-2124G 4C/4T 3.4GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2126G 6C/6T 3.3GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2144G 4C/8T 3.6GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2146G 6C/12T 3.5GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2174G 4C/8T 3.8GHz 8MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2176G 6C/12T 3.7GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2186G 6C/12T 3.8GHz 12MB 2666MHz Turbo 95W
B1034-V2 GFM0412SS --- --- --- ---
Core i3 (Coffee Lake-S)
Core i3-8100 4C/4T 3.6GHz 6MB 2400MHz 65W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Pentium (Coffee Lake-S)
Pentium Gold G5400 2C/2T 3.7GHz 4MB 2400MHz 54W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2xxx (without Graphics)
Xeon E-2224 4C/4T 3.4GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2234 4C/8T 3.6GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2236 6C/12T 3.4GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2xxxG (with Graphics)
Xeon E-2224G 4C/4T 3.5GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2226G 6C/6T 3.4GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2244G 4C/8T 3.8GHz 8MB 2666MHz Turbo 71W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2246G 6C/12T 3.6GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2274G 4C/8T 4.0GHz 8MB 2666MHz Turbo 83W
B1034-V2 GFM0412SS --- --- --- ---
Xeon E-2276G 6C/12T 3.8GHz 12MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2278G 8C/16T 3.4GHz 16MB 2666MHz Turbo 80W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Xeon E-2286G 6C/12T 4.0GHz 12MB 2666MHz Turbo 95W
B1034-V2 GFM0412SS --- --- --- ---
Xeon E-2288G 8C/16T 3.7GHz 16MB 2666MHz Turbo 95W
B1034-V2 GFM0412SS --- --- --- ---
Core i3 (Coffee Lake-S)
Core i3-9100 4C/4T 3.6GHz 6MB 2400MHz Turbo 65W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Pentium (Coffee Lake-S)
Pentium Gold G5420 2C/4T 3.8GHz 4MB 2400MHz 54W
B1034-V1 FFB0412EN B1034-V2 FFB0412EN B1034-V2 GFM0412SS
Coffee Lake-S
(LGA1151)
ATD35 ATD40 ATD45
Figure 152: Types of heat sinks (A)
Processor (CPU)
242 Upgrade and Maintenance Manual RX1330 M4
