Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

11 Processor (CPU)
11.1
Safety notes
CAUTION
▶
Do not install unsupported CPUs. For more information on
supported CPUs, see "Basic information" on page 19
.
▶
Circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Always discharge static
build-up (e.g. by touching a grounded object) before handling
electrostatic sensitive devices (ESDs).
▶
Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
▶
When removing or installing CPUs, be careful not to touch or bend
the spring contacts on the CPU sockets.
▶
Never touch the underside of the CPUs. Even minor soiling such as
grease from the skin can impair the CPU’s operation or destroy the
CPUs.
▶
For more information, see "Important information" on page 29.
11.2 Basic information
Supported CPUs
–
one Intel® Xeon® CPU E21xx or E22xx or Pentium or Core i3, up to 95 W,
up to 8 cores
–
one CPU socket LGA 1
151
For system relevant information, see the hardware configurator of your
server available online at the following address:
httpss://ts.fujitsu.com/products/standard_servers/index.htm
For Japan:
https://www.fujitsu.com/jp/products/computing/servers/primergy/
RX1330 M4 Upgrade and Maintenance Manual 241

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
