Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Removing the front panel on QRL
The front panel on QRL and the front panel cable are combined in one
spare part.
Figure 190: Disconnecting the front panel cable
▶
Pull up the locking bar (1).
▶
Remove the front panel cable (2).
▶
Thread the front panel cable (flat cable) through the opening (see circle).
Front panel
RX1330 M4 Upgrade and Maintenance Manual 279

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
