Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Concluding steps
▶
Install the riser module 1, see "Installing a riser module" on page 61
.
▶
"Installing the air duct" on page 64.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
15.6 M.2 SSD
15.6.1 Installing an M.2 SSD
The system board offers two M.2 slots (Key M) with support for 80 mm and
110 mm long M.2 SSDs.
With an M.2 SSD an internal SSD is offered. This SSD can be configured as a
boot device or data storage device.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
If applicable, remove riser modules 2 and 3, see "Removing a riser module"
on page 59.
System board and components
310 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
