Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Removing the air duct" on page 63.
Removing the Dual microSD 64GB Enterprise
Figure 223: Removing the Dual microSD 64GB Enterprise
▶
Disconnect the cable from the connector "ROC" on the system board.
▶
Pull the Dual microSD 64GB Enterprise out of its connector
.
System board and components
320 Upgrade and Maintenance Manual RX1330 M4
