Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Figure 222: Installing the Dual microSD 64GB Enterprise
▶
Insert the Dual microSD 64GB Enterprise into the system board connector
"Internal USB 3.0" on the system board.
▶
Connect the cable to the connector "ROC" on the system board.
Concluding steps
▶
"Installing the air duct" on page
64
.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
15.7.2 Removing the Dual microSD 64GB Enterprise
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
System board and components
RX1330 M4 Upgrade and Maintenance Manual 319

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
