Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Replacing the Dual microSD 64GB Enterprise
▶
Remove the defective Dual microSD 64GB Enterprise, see "Removing the
Dual microSD 64GB Enterprise" on page 320
.
▶
Remove both microSD cards from the defective Dual microSD 64GB
Enterprise.
Proceed as described in the following:
Figure 224: Removing the microSD card
▶
To eject the microSD card, gently push it in and then let go (1).
▶
Pull the microSD card straight out of its slot (2).
▶
Install both microSD cards on the new Dual microSD 64GB Enterprise.
Proceed as described in the following:
Figure 225: Installing the microSD card
▶
With the label facing up, insert the microSD card into the microSD slot on
the controller (1) until it locks in place (2).
System board and components
322 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
