Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

15.8 System board
15.8.1 Replacing the system board
Field Replaceable Unit
(FRU)
Hardware: 40 minutes
Software: 20 minutes
Tools: Replacing the system board:
– Phillips PH2 / (+) No. 2 screw driver
– Magnifying glass for inspecting CPU socket springs
(recommended)
Replacing the TPM:
– Bit screw driver
– Flat nose pliers
–
TPM bit insert
(*)
–
Thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
Note on TPM
The system board can be equipped with an optional TPM. This module
enables third party programs to store key information (e. g. drive
encryption using Windows Bitlocker Drive Encryption).
If the customer is using TPM functionality, the TPM has to be removed
from the defective system board and connected to the new system
board. For more information, see "Replacing the TPM" on page 303.
The TPM has to be enabled in the system BIOS.
System board and components
RX1330 M4 Upgrade and Maintenance Manual 325

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
