16.1 Mechanical overview
16.1.1
Server front
16.1.1.1 2.5-inch HDD/SSD configuration
The PRIMERGY RX1330 M4 server is available as a rack model.
Figure 228: Server front with up to 4x 2.5-inch HDDs/SSDs
1 ID card
2 Front VGA (option) / dummy cover
3
Front panel module
4 ODD (option) / dummy cover
5 Up to 4x 2.5-inch HDDs/SSDs
Figure 229: Server front with up to 8x 2.5-inch HDDs/SSDs
1 ID card
2
Front VGA (option) / dummy cover
3
Front panel module
4 ODD (option) / dummy cover
5 Up to 8x 2.5-inch HDDs/SSDs
