16.1.3 Server interior
Example with 3.5-inch HDDs and hot-plug PSUs
Figure 234: Server interior - 3.5-inch HDDs and hot-plug PSUs
1 Up to 2 hot-plug PSUs / dummy cover
2
Front panel module
3
Up to 4x 3.5-inch HDDs / dummy
modules
4 ODD (option) / dummy cover
5 Fan modules (5x)
6 CPU
7 Main memory
8 Riser module 1
9 Riser module 2
10 Riser module 3
