Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Replacing the TPM:
–
Bit screw driver
–
TPM bit insert
(*)
– Flat nose pliers
–
Thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
▶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later.
Preliminary steps
▶
"Suspending BitLocker functionality" on page 61.
▶
"Unlocking the server" on page 39
▶
"Removing the bay cover" on page 40
▶
"Shutting down the server" on page 41
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
▶
Remove all expansion cards, see "Removing an expansion card" on
page 119.
Before removing the expansion cards, take a note on the installation
slot number for each card. Ensure that you reinstall the card in the
slot it was located before the replacement.
System board and components
TX1310 M5 Upgrade and Maintenance Manual 193
