Removing the defective TPM
▶
Remove the TPM, see "Removing the TPM" on page 191.
▶
Leave the TPM spacer on the bottom system board when removing the
defective TPM.
Installing the new TPM
The TPM spacer is already present on the system board.
▶
Install the TPM, see "Installing the TPM" on page 186.
Concluding steps
▶
Install all expansion cards, see "Installing an expansion card" on page
118.
Ensure that you reinstall each card in the slot it was located before
the replacement.
▶
"Reassembling" on page 50
.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57
▶
"Installing the bay cover" on page 58
▶
"Locking the server" on page 59
▶
"Resuming BitLocker functionality" on page 68.
You can find information on configuring the TPM in the corresponding
BIOS Setup Utility reference manual.
15.5 M.2 SSD
15.5.1 Slots and bolts for M.2 SSDs
The system board of
fers two M.2 slots (Key M) with support for 80 mm and
110 mm long M.2 SSDs.
System board and components
194 Upgrade and Maintenance Manual TX1310 M5
