Align the two pins on the fixation plate with the screw holes in the ODD.
▶
Attach the fixation plate to the left side of the new ODD.
▶
Install the new ODD, see "Installing the ODD" on page
158
.
Concluding steps
▶
"Reassembling" on page 50.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Installing the bay cover" on page 58.
▶
"Locking the server" on page 59.
▶
"Reconfiguring the backup software solution" on page 64.
▶
"Resuming BitLocker functionality" on page 68.
12.4 RDX drive
12.4.1 Installing the RDX backup drive
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Thin slotted screw driver (for removing the bracket wall)
–
Phillips PH2 / (+) No. 2 screw driver (for removing the PSU)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 61
.
▶
"Unlocking the server" on page 39.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
Accessible drives
TX1310 M5 Upgrade and Maintenance Manual 165
