Figure 101: Accessible drive bays
Sequence Accessible drive Bay Max. number
1 Slimline ODD 1 1
2 RDX backup drive 2 1
Table 4: Accessible drive mounting sequence
12.3 Optical disk drive (ODD)
12.3.1
Installing the ODD
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Thin slotted screw driver (for removing the bracket wall)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 61
.
▶
"Unlocking the server" on page 39.
Accessible drives
158 Upgrade and Maintenance Manual TX1310 M5
