11.3 Upgrading or replacing the CPU
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
CAUTION
CPUs are extremely sensitive to electrostatic discharge and therefore
must always be handled with care.
▶
After a CPU has been removed from its protective sleeve or from its
socket, place it upside down on a nonconducting, antistatic surface.
▶
Never push a CPU over a surface.
Preliminary steps
▶
"Suspending BitLocker functionality" on page
61.
▶
"Unlocking the server" on page
39.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
▶
"Removing the top HDD cage" on page 46.
Processor (CPU)
TX1310 M5 Upgrade and Maintenance Manual 135
