Concluding steps
▶
"Reassembling" on page 50
.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Installing the bay cover" on page 58.
▶
"Locking the server" on page 59.
7.3.3 Replacing a 2.5-inch HDD module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
CAUTION
All HDD/SSD modules (drives) must be uniquely identified so that they
can be reinstalled in their original bays later. If this is not done, existing
data can be lost.
Preliminary steps
▶
"Unlocking the server" on page 39.
▶
"Removing the bay cover" on page
40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
Removing the defective 2.5-inch HDD
▶
Remove the HDD, see "Removing a 2.5-inch HDD" on page 87.
Hard disk drives (HDD)
88 Upgrade and Maintenance Manual TX1310 M5
