"Connecting the power cord" on page 56
.
▶
"Switching on the server" on page 57.
▶
"Installing the bay cover" on page 58.
▶
"Locking the server" on page 59.
▶
"Reconfiguring the backup software solution" on page 64.
▶
"Resuming BitLocker functionality" on page 68.
12.4.3 Replacing the RDX backup drive
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for removing the PSU)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 61
.
▶
"Removing backup and optical disk media" on page 63.
▶
"Verifying and configuring the backup software solution" on page 63.
▶
"Unlocking the server" on page 39.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
▶
"Removing the top HDD cage" on page 46.
Removing the defective RDX backup drive
▶
Remove the defective RDX backup drive, see "Removing the RDX backup
drive" on page 170.
▶
Remove the fixation plate from the left side of the drive.
Accessible drives
