SATA connectivity
Controller Channel Connection
PCI SATA controller 1 Drives 1-4
7.3 2.5-inch HDD/SSD configurations
7.3.1 Installing a 2.5-inch HDD module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Unlocking the server" on page
39
.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
▶
Locate the correct drive bay, see "Mounting order" on page 82.
Installing a 2.5-inch HDD
HDDs on the bottom and HDDs on the front can be installed in the same
way.
Hard disk drives (HDD)
TX1310 M5 Upgrade and Maintenance Manual 83
