Fujitsu PRIMERGY TX1310 M5 User Manual

12.3.3 Replacing the ODD
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
Preliminary steps
▶
"Suspending BitLocker functionality" on page 61
.
▶
"Removing backup and optical disk media" on page 63.
▶
"Verifying and configuring the backup software solution" on page 63.
▶
"Unlocking the server" on page 39.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
Replacing the ODD
▶
Remove the defective ODD, see "Removing the ODD" on page 163.
▶
Remove the fixation plate from the left side of the defective ODD.
Figure 107: Attaching the fixation plate to the ODD
Accessible drives
164 Upgrade and Maintenance Manual TX1310 M5
