Concluding steps
▶
"Reassembling" on page 50
.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57
▶
"Installing the bay cover" on page 58
▶
"Locking the server" on page 59
16.4 Replacing the HDD cable (bottom HDD
cage)
The following steps are only required in case of a defective cable.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
"Unlocking the server" on page
39
▶
"Removing the bay cover" on page
40
▶
"Shutting down the server" on page 41
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
Cables
