Figure 1: ESD label
The ESD label can be different.
When you handle ESD modules, you must always observe the following points:
▶
Switch off the server and remove the power plugs from the power outlets
before installing or removing ESD modules.
▶
The circuit boards and soldered parts of internal options are exposed and
can be damaged by static electricity
. To ensure reliable protection, you must
wear an earthing band on your wrist when working with ESD modules and
connect it to an unpainted, conducting metal part of the server.
▶
Any devices or tools that are used must be free of electrostatic charge.
▶
Wear a suitable grounding cable that connects you to the external chassis of
the server.
▶
Always hold ESD modules at the edges or at the colored touch points.
▶
Do not touch any connectors or conduction paths on an ESD module.
▶
Place all the components on a pad which is free of electrostatic charge.
For a detailed description of how to handle ESD modules, see the
relevant European or international standards (EN 61340-5-1, ANSI/
ESD S20.20).
Important information
32 Upgrade and Maintenance Manual TX1310 M5
